These files contain one or more macro functions that can be added to the Quick Macro Panel found in your Tecplot software. Splits an I ordered zone into smaller zones, based on a user provided number of points for each smaller zone. Splits an I ordered zone into smaller zones based on the values of one of the variables. Switches the I and J indices of an IJ-ordered zone.Ĭreates a variable which is used to number the zones. Great for making propellers, turbines, etc.
Macro to create a plot where scatter symbols are drawn on top of a contour plot where the scatter symbols represent the positions of the minimum and maximum contour value.Ĭopys a zone multiple times and rotate the duplicates around an XY point. Integrates the volume below an IJ ordered surface in 2D mode, given a contour variable. This macro only works on I-, IJ-, and IJK-ordered data.Ĭalculates the difference between 2 i-ordered XY curves (zones) with different numbers of points. This AVERAGE is calculated for all of the points in the lowest ACTIVE zone in your dataset.
Each point will be colored according to the value of a 4th variable.Ĭalculates the total area of all cells which lie above a specified contour variable limit.Ĭreates a new variable that is set to the AVERAGE of a chosen variable. Same as the “Animate IJK Planes” feature under the Tools/Animate menu, except only 1 IJK-ordered zone is animated.įor a 3D i-ordered data set, points will be displayed singly, from first to last, with the index value displayed on each. It activates the first zone of each set, then the second zone of each set, etc.Īnimates zones where n consecutive zones are active throughout the animation.Īnimates the contents of multiple frames simultaneously. Makes a group of points follow an XY curve.Īnimates zones so that one or more zones remain active throughout.Īnimates two sets of zones loaded to same frame. mcr files below, use a text editor to modify it to fit your needs, open it in your Tecplot software, and you should be ready to go.
#Tecplot probe 2d macro movie
Macro variables, commands, batch processes, and movie file creation are explained in the Tecplot 360 and Tecplot Focus Scripting Guides and User’s Manual in our Documentation. Better yet, the Tecplot support and development teams have put together these handy Basic Macros and Quick Macro Panel (QMP) files that can be customized to help you automate a variety of tasks. They are recordable, easy to edit, and don’t require any development experience. Macros are useful for streamlining repetitive operations, executing multi-step tasks quickly, and performing operations that can’t easily be done interactively. Basic Macros | Quick Macro Panel (QMP) | FAQs
